Move License; Perform A Factory Reset - ASCOM d62 Talker Configuration Manual

Configuration Manual
Ascom d62 DECT Handset
4.4.4

Move License

Note: This feature requires Device Manager that supports the move license feature, and a
connection to the license server.
A license can be moved from a d62 Messenger or d62 Protector to another unlicensed
handset of the same device type (that is d62 Talker).
Note: A Bluetooth Data Profile license can only be moved to a handset with Bluetooth. In
addition, a Shared Phone license can only be moved to a IP-DECT handset.
An example of when to use the Move license command is when there is an unused d62
Talker and a d62 Protector with a broken display. Use the Move license command to move
the Protector license to the d62 Talker which becomes a d62 Protector. Then the broken
handset (which is now a d62 Talker) can be sent for service.
1 Select the "Licenses" tab.
2 Select the device whose license shall be moved. The selected row is highlighted.
3 In the License menu, select "Move license..." or right-click and select "Move license...".
The Move license window appears.
4 Select the device that shall receive the license. Click "OK".
If no devices are shown in the Move license window, there are no devices that are
selectable to move the license to.
The device whose license that has been moved has now become a d62 Talker. The device
that received the license is still shown as a d62 Talker. Select this device and do the
following:
5 In the Licenses menu, select "Refresh" to complete the transfer of the license. The
device is now a d62 Messenger or d62 Protector (depends on which license that was
moved to the device).
See also 4.6 Replacement Procedure Choice Guide
move user parameters and contacts to another handset.
4.5

Perform a Factory Reset

When a factory reset is done on a handset, all configuration settings are restored to default
values and PBX subscriptions and all data are removed. This includes contacts, messages etc.
The software is left intact.
Factory Reset using PDM
1 In PDM, click the Device tab and mark the handset to be factory reset. Note that the
handset must be online.
2 In the Device menu, select "Factory reset". Alternatively, right-click the handset and
select "Factory reset".
3 A Reset devices dialog appears, click "Yes". The handset restarts.
Factory Reset using Handset
A handset can be factory reset from the Admin menu:
1 To activate the Admin Menu, enter the Call time screen and press > * < < * <.
2 Select "Factory Reset".
3 A Reset portable? dialogue appears, press "Yes". The handset is restarted.
31 October 2013 / Ver. J
on page 14 for information on how to
TD 92639EN
13
