Configuration Manual
Ascom d62 DECT Handset
1 Select Settings > Sound and Alert.
2 In the Message alert drop-down list, select "Enhanced beeps according to beep code".
Custom sounds according to beep code
Beep code sent from a system or application
Beep code 0
Beep codes 1- 7
The handset can play customized message alerts that are mapped to beep codes. The
message alerts must first be customized and then mapped to the beep codes.
Customized sounds may also be mapped to enhanced beep codes, as described in
Customize the Default Handset Beeps
Tip: It is recommended to use this feature to create a message a message alert that sounds
like an item of equipment, such as a respirator, that generates an alarm.
1 Select Settings > Custom Sounds > Custom Sound X (where X represent 1 - 10).
2 Set the following parameters:
• Label - The name of the custom sound (required). The name is visible when
mapping the custom sound to a beep code later on.
• Melody - The text string represents a non-polyphonic sound. By default, example
of melodies are set for Custom Sound 1 - 7. See also
Custom Sound
Customize the Default Handset Beeps
• Beat - The tempo in beats per minute to be used when playing the sound.
• Style - The ratio of note to rest period to be used when playing the sound.
• Instrument - The instrument to be used when playing the sound.
Map Beep Codes to Customized Sounds
1 Select Sound and Alerts > Custom Message Alert
2 In the Beep code drop-down lists, select the customized sounds to be used for
respectively beep codes.
Enable Customized Sound
1 Select Settings > Sound and Alert.
2 In the Message alert drop-down list, select "Custom sounds according to beep code".

5.27.2 Example of TTR and TTP settings

Example 1
This example describes the message handling with the following message settings:
• TTP= Prioritize forever
• TTR= Close manually
Tip: It is recommended to use these settings if messages with the highest priority always
shall be displayed until the user closes the current message.
31 October 2013 / Ver. J
on page 69.
on page 68. For enhanced beep code mappings, also see
on page 69.
The handset plays:
No message alert is played
Corresponding customized sound
