Handset Configuration

5.16 Action when Handset is Placed In Charger

5.16.1

In Charger Action when not in Call

The handset can be configured to perform an action when it is placed in a charger. The selected action is
only performed when no call is established. When the handset is removed from the charger, it returns to
previous settings.
If the Logout action is enabled, the handset needs to be logged on manually when it is removed
from the charger.
1. Select Connections → In charger.
2. In the In charger action drop-down list, select one of the following:
− No action- no action is performed when handset is placed in charger.
− Switch off - the handset is switched off when placed in charger.
− Redirect - the handset redirects all calls and messages (only available for some handset variants,
see 1.1 Functionality Matrix, page
Device Manager.
The destination number must be programmed in the PBX to be able to redirect calls and
messages.
− Sound off 1 - the handset is silenced when placed in charger.
Messages with breakthrough, for example, messages with a high or alarm priority, are not
muted. To mute all messages, regardless of priority, also set the Show and indicate
incoming messages parameter.
− Logout - the handset is logged off when placed in charger. This option is only visible if the Shared
Phone feature is enabled.
− Message absence - if a message is sent from a system, it is notified that the handset is absence.
− Change profile - the handset changes profile when placed in charger.
In the Change to profile drop-down list, select the profile to be used. By default, only the profile
Normal is selectable. If configured, additional profiles are visible, see
− Show and indicate incoming messages and PTT calls
Determines how incoming messages are displayed or indicated when the handset is placed in
charger. If this parameter is set to No, the message alert, if any, is muted and only the New message
icon is displayed. The messages are stored as unread messages in the Messaging Inbox.
All incoming messages are affected by this setting; that is PTT invitation received as
message, and all other messages regardless of priority (even messages with breakthrough
such as high/alarm priority). To only silence messages without breakthrough (low/normal
priority), set the Sound off parameter instead.
5.16.2

In Charger Action when in Call

The handset can be configured to end a call, or turn on the loudspeaker when it is placed in a charger
during a call. If the handset is removed from the charger during the call, it does not revert to the previous
settings.
1. Select Connections → In charger.
1. If the parameter "Turn off sound" is set to "No", the handset is not muted when placed in charger.
26
1) when placed in charger. Redirect can only be set in WinPDM/
CONFIGURATION MANUAL
Ascom d83 DECT Handset
5.45.1 User Profiles, page
