Handset Configuration

5.10 Own Line Settings

Use own line settings if the same phonebook is to be used in different systems and in different countries.
The own line settings enables:
• Calling numbers stored with a "+" sign for the international access code. The same local phonebook can
be used in different countries.
• The recognition of incoming internal or external calls as numbers stored in international format in the
local phonebook. The same phonebook can be used in different systems.
For this feature to work, numbers must be stored in the local phonebook in international format with a "+"
sign for the international access code. Also, the Own Line parameters must be configured via the WinPDM/
Device Manager.
5.11

Configure DTMF

Some legacy systems and PBXs require that the handset sends DTMF tones when pressing or releasing the
PTT button or when pressing the On-hook key to end a call.
This is only applicable for some handset variants, see
5.11.1

Send DTMF Tone when Pressing On-Hook key

1. Select Settings → DTMF.
2. In the On-hook DTMF tone drop-down list, select the DTMF tone to be sent when the On-hook key is
pressed.
To disable the DTMF tone, select Not used.
5.11.2

Send DTMF Tones when Pressing or Releasing the PTT Button

1. Select Settings → DTMF.
2. In the Push to talk DTMF tones drop-down list, select On.
3. In the PTT DTMF ton on push drop-down list, select the DTMF tone to be sent when pressing the PTT
button.
4. In the PTT DTMF ton on release drop-down list, select the DTMF tone to be sent when releasing the
PTT button.
To disable the DTMF tones, select Off in the Push to talk DTMF tones drop-down list.

5.12 Uploadable Language

The handset can be loaded with one additional language. The language file is generated via an Excel file.
Excel language files are available from the handset supplier.
If another language file is uploaded, the first additional language is overwritten.
Certain special characters are allowed when generating the language file, see information in the Excel file.
To upload an additional language, the WinPDM/Device Manager is used, go to the devices tab and select
devices. In the Device menu, select Upload language....
22
CONFIGURATION MANUAL
Ascom d83 DECT Handset
1.1 Functionality Matrix, page
TD 93426EN / 28 January 2022 / Ver. C
