1.2 Typical System Installation

The Singlewire-enabled Voice-over-IP (VoIP) VoIP Emergency Intercom is a SIP endpoint designed
to provide VoIP phone connectivity in a tamper proof and secure package.
Figure 1-2
system.
Door Strike VoIP Intercom
Operations Guide
illustrates how the VoIP Emergency Intercom can be installed as part of a VoIP phone
Figure 1-2. Typical Installation—Door Entry/Access Control
