A.2 PCB Dimensions
Figure A-5 shows the PCB dimensions and the intrusion sensor range.
Figure A-5. PCB Dimensions and Intrusion Sensor Range
0.118 [3.00]
ø0.138 [ø3.51]
Fits #6-32 Machine Screw
0.551 [14.00]
(4 Places)
Effective Range for
Instrusion
1.083 [27.52] Intrusion Sensor to Function
Sensor
JP10
from 3 mm to 14 mm
J10
J12
J8
J1
J5
J2
J3
J4
RTFM
J9
J7
J6
TOP SIDE
BOTTOM SIDE
0.501 [12.73]
4.200 [106.68] 2.300 [58.42]
DIMENSIONS ARE IN INCHES [MILLIMETER]
0.532 [13.53]
