2.9.6 RTFM Button

When the Intercom is operational and linked to the network, you can use the Reset Test Function
Management (RTFM) button (see
Intercom's IP Address and test to see if the audio is working.
Note
2.9.6.1 Announcing the IP Address
To announce a device's current IP address:
1. Press and release the RTFM button (see
Note
Note
Operations Guide
You must do these tests prior to final assembly.
The device will use DHCP to obtain the new IP address (DHCP-assigned address or default
to 10.10.10.10 if a DHCP server is not present).
Pressing and holding the RTFM button for longer than five seconds will restore the device to
the factory default settings.
930947A
Figure 2-10) on the Intercom board to announce and confirm the
Figure 2-10. RTFM Button
Figure 2-11) within a five second window.
Figure 2-11. RTFM Button
Installing the VoIP Emergency Intercom
RTFM
RTFM
