1.2 Typical System Installation
The Voice-over-IP (VoIP) Intercom is a SIP endpoint designed to provide VoIP phone connectivity in
a tamper-proof and secure package.
The following figures illustrate how the device can be installed as part of a VoIP phone system.
Figure 1-2. Typical Installation—Door Strike Intermediate Relay Module
Door Strike Intermediate
Door Strike
Relay Module
Figure 1-3. Typical Installation—Networked Door Strike Intermediate Relay Module
Networked Door Strike
Door Strike
Intermediate Relay Module
Operations Guide
802.3af Compliant Ethernet Switch
1
2
3
4
Intercom
802.3af Compliant Ethernet Switch
1
2
3
4
Intercom
930796N
5
6
IP Phone
5
6
IP Phone
Product Overview
Typical System Installation
IP PBX Server
IP PBX Server
CyberData Corporation
2
