Mounting the Indoor Intercom

Wall Mounting Components

Figure A-4

shows the maximum recommended wall cutout dimensions.

Figure A-4. Maximum Recommended Wall Cutout Dimensions

0.38 [9.5]

ø0.19 [ø4.8]

(4 Places)

0.50 [12.8]

2.65 [67.3]

3.40 [86.4]

DIMENSIONS ARE IN INCHES [MILLIMETER]
