CyberData 11304 Operation Manual page 22

Operations Guide
J9
RTFM
Connector
JP1
J1
J3
J5
J9
J12
RTFM
a.Do not install a jumper. Momentary short to reset. Permanent instal-
lation of a jumper would prevent the board from running all together.
Figure 2-8. Connector Locations
J1
Table 2-3. Connector Functions
Function
a
Reset jumper
PoE Network Connection (RJ-45 ethernet)
Terminal Block (see Figure
JTAG (Factory Use Only)
Auxiliary Strobe Connector — Not Used
Reserved (Factory Use Only)
See Section 2.9.6, "RTFM
930947A
Installing the VoIP Emergency Intercom
Identifying the VoIP Intercom Connectors
J5
J12
J3
2-3)
Button".
CyberData Corporation
15
