Figure A-2
Note
Operations Guide
shows a wall mounting option.
Be sure to connect the VoIP Emergency Intercom to the Earth Ground.
Pick One of Four Mounting Hole
for Ground Wire Connection
Figure A-2. Wall Mounting Option
Backplate
Cable
Entry
Slot
Mounting
Screw (3x)
930947A
Mounting the Indoor Intercom
Wall Mounting Components
Pre Drill Holes
(4 Places) on Wall
Cable
Slots
Closed
Cutout
Network Cable &
Ground Wire
(Not Provided)
121001A
Screw
Accessory Kit
CyberData Corporation
70
Wall
