2. On the Network Configuration page, enter values for the parameters indicated in
Web Page Item
Stored Network Settings
IP Addressing
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
Hostname
VLAN ID (0-4095)
VLAN Priority (0-7)
DHCP Timeout
DHCP Timeout in seconds
Note
Operations Guide
Table 2-8. Network Configuration Parameters
You must click on the Save button and then the Reboot button for the changes to take
effect.
930947A
Description
Select either DHCP IP Addressing or Static IP Addressing by
marking the appropriate radio button. If you select Static, configure
the remaining parameters indicated in
go to Step Note.
Enter the Static IP address.
Enter the Subnet Mask address.
Enter the Default Gateway address.
Enter the DNS Server 1 address.
Enter the DNS Server 2 address.
This is the hostname provided to the DHCP server. This can be used
in conjunction with a DNS server to address the device by host name
instead of by IP address. Check your DHCP server and DNS server
documentation for more information.
Enter the VLAN ID number.
Note: The device supports 802.11Q VLAN tagging support. The
switch port connected to the device will need to be in "trunking mode"
for the VLAN tags to propagate.
Enter the VLAN priority number.
Enter the desired timeout duration (in seconds) that the device will
wait for a response from the DHCP server before defaulting back to
the stored static IP address.
Note: A value of -1 will cause the device to retry indefinitely and a
value of 0 will cause the device to reset to a default of 60 seconds.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Installing the VoIP Emergency Intercom
Configure the Network Parameters
Table
Table 2-8 . If you select DHCP,
