1.2 Typical System Installation

The Voice-over-IP (VoIP) Intercom is a Power-over-Ethernet (PoE 802.3af) and VoIP two-way
communications device that easily connects into existing local area networks (LANs) with a single
cable connection. The intercom is compatible with most SIP-based IP PBX servers that comply with
SIP RFC 3261.
Figure 1-2
phone system.
Door Strike
GENERAL ALERT
GENERAL ALERT
GENERAL ALERT
GENERAL ALERT
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
illustrates how the VoIP Indoor Intercom with Keypad can be installed as part of a VoIP
Figure 1-2. Typical Installation—Door Entry/Access Control
Generic PoE Switch
1 2 3
VoIP Intercom VoIP Intercom
Warning
Electrical Hazard:
Warning
Electrical Hazard:
according to all local electrical and building codes.
Warning
Electrical Hazard:
the floor/wall in accordance with the installation instructions.
Warning
The PoE connector is intended for intra-building connections only and does not
route to the outside plant.
930935A
4 5 6
IP Phone
The VoIP Intercom enclosure is not rated for any AC voltages.
This product should be installed by a licensed electrician
To prevent injury, this apparatus must be securely attached to
Product Overview 2
Typical System Installation
Informacast Server
CyberData Corporation
