CyberData 011304 Quick Start Manual

Informacast enabled emergency intercom
Hide thumbs Also See for 011304:
1
2
3
4

Advertisement

Table of Contents

The IP Endpoint Company

1.0 Out-of-Box and Prior to Final Installation

1.1. Verify that you have received all of the parts listed on the Installation Quick
Reference placemat.
1.2. Download the current manual, otherwise known as an Operations Guide,
which is available in the Downloads tab at the following webpage:
http://www.cyberdata.net/products/011304/
Note You can also navigate to the Downloads tab by going to
www.CyberData.net
the following figures:
1
OUR PRODUCTS
A
VOIP PRODUCTS
B
INFORMACAST ENABLED
C

2.0 Select Power Source

PoE Switch
Set PoE power type to Class 0 = 15.4W
Quick Start Guide
InformaCast Enabled Emergency Intercom
Quick Start Guide
and following the steps that are indicated by
Make sure port is not in trunk mode
Set port to full duplex/ 100Mbps
2
011304 INFORMACAST ENABLED
EMERGENCY INTERCOM
3
PoE Injector
CAT6 cable recommended—
for longer distances
Be sure you are using a non-PoE switch or port
Downloads
931623C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 011304 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CyberData 011304

Summary of Contents for CyberData 011304

  • Page 1 Note You can also navigate to the Downloads tab by going to www.CyberData.net and following the steps that are indicated by the following figures: OUR PRODUCTS 011304 INFORMACAST ENABLED EMERGENCY INTERCOM VOIP PRODUCTS INFORMACAST ENABLED Downloads 2.0 Select Power Source...
  • Page 2 3.0 Power Test 3.1. Plug in the CyberData device and monitor the LED activity above the ethernet port on the back of the device. See the following figure: Link/Activity LED (Green) 100Mb Link LED (Amber) 3.2. The green Link/Activity LED blinks off once during the boot up process when the device begins DHCP addressing and autoprovisioning attempts, and then comes on again and remains constant (solid green).
  • Page 3 4.0 InformaCast Configuration File Retrieval 4.1. DHCP should be enabled. After the device initializes, it will send a broadcast to the DHCP server to ask for the location of its InformaCastSpeaker.cfg configuration file. 4.2. SLP or TFTP? • SLP should be enabled on InformaCast version 5.0.4 or higher. SLP is an InformaCast protocol introduced in InformaCast version 5.0.4.
  • Page 4 6.0 Contacting CyberData VoIP Technical Support You are welcome to call CyberData VoIP Technical Support at 831-373-2601 x333. Business hours are 7:00 AM - 5:00 PM Pacific Time, Monday through Friday. We encourage you to access our Technical Support help desk at the following address: http://support.cyberdata.net/...
