1.2 Typical System Installation

The Voice-over-IP (VoIP) VoIP V3 Indoor Intercom is a SIP endpoint designed to provide VoIP phone
connectivity in a tamper proof and secure package.
Figure 1-2
system.
Door Strike
Operations Guide
illustrates how the VoIP V3 Indoor Intercom can be installed as part of a VoIP phone
Figure 1-2. Typical Installation—Door Entry/Access Control
Generic PoE Switch
1
VoIP Intercom
Warning
Electrical Hazard:
voltages.
GENERAL ALERT
Warning
Electrical Hazard:
according to all local electrical and building codes.
GENERAL ALERT
Warning
Electrical Hazard:
the floor/wall in accordance with the installation instructions.
GENERAL ALERT
Warning
The PoE connector is intended for intra-building connections only and does not
route to the outside plant.
GENERAL ALERT
2 3 4 5 6
VoIP Intercom
The VoIP V3 Indoor Intercom enclosure is not rated for any AC
This product should be installed by a licensed electrician
To prevent injury, this apparatus must be securely attached to
930500I
Typical System Installation
IP Phone
IP PBX Server
