Rtfm Button - CyberData 011186 Operation Manual

2.3.6 RTFM Button

When the Intercom is operational and linked to the network, you can use the Reset Test Function
Management (RTFM) button (see SW1 in
confirm the Intercom's IP Address and test to see if the audio is working.
Note
2.3.6.1 Announcing the IP Address
To announce a device's current IP address:
1. Press and release the RTFM button (see SW1 in
Note
Note
Operations Guide
You must do these tests prior to final assembly.
The device will use DHCP to obtain the new IP address (DHCP-assigned address or default
to 10.10.10.10 if a DHCP server is not present).
Pressing and holding the RTFM button for longer than five seconds will restore the device to
the factory default settings.
Figure 2-10. RTFM Button (SW1)
930796N
Figure 2-9) on the Intercom board to announce and
Figure 2-9. RTFM Button (SW1)
Figure
Installing the VoIP Outdoor Intercom
SW1
2-10) within a five second window.
SW1
CyberData Corporation
16
Intercom Setup
