Specifications

9 Specifications

9.1 General Specifications

Mains supply 200 - 240 VAC - Normal overload 110% for 1 minute
Frequency converter
Typical Shaft Output [kW]
IP 20 / Chassis
(A2+A3 may be converted to IP21 using a conversion kit. (Please
see also items Mechanical mounting in Operating Instructions and
IP 21/Type 1 Enclosure kit in the Design Guide.))
IP 55 / NEMA 12
IP 66 / NEMA 12
Typical Shaft Output [HP] at 208 V
Output current
9 9
Max. input current
Table 9.1: Mains Supply 200 - 240 VAC
134
®
VLT HVAC Drive Operating Instructions
Continuous
(3 x 200-240 V ) [A]
Intermittent
(3 x 200-240 V ) [A]
Continuous
kVA (208 V AC) [kVA]
Max. cable size:
(mains, motor, brake)
2 2)
[mm /AWG]
Continuous
(3 x 200-240 V ) [A]
Intermittent
(3 x 200-240 V ) [A]
1)
Max. pre-fuses [A]
Environment
Estimated power loss
4)
at rated max. load [W]
Weight enclosure IP20 [kg]
Weight enclosure IP21 [kg]
Weight enclosure IP55 [kg]
Weight enclosure IP 66 [kg]
3)
Efficiency
®
MG.11.AD.02 - VLT
P1K1 P1K5
1.1 1.5
A2 A2
A4/A5 A4/A5
A5 A5
1.5 2.0
6.6 7.5
7.3 8.3
2.38 2.70
5.9 6.8
6.5 7.5
20 20
63 82
4.9 4.9
5.5 5.5
9.7/13.5 9.7/13.5
9.7/13.5 9.7/13.5
0.96 0.96
is a registered Danfoss trademark
P2K2 P3K0 P3K7
2.2 3 3.7
A2 A3 A3
A4/A5 A5 A5
A5 A5 A5
2.9 4.0 4.9
10.6 12.5 16.7
11.7 13.8 18.4
3.82 4.50 6.00
4/10
9.5 11.3 15.0
10.5 12.4 16.5
20 32 32
116 155 185
4.9 6.6 6.6
5.5 7.5 7.5
9.7/13.5 13.5 13.5
9.7/13.5 13.5 13.5
0.96 0.96 0.96
