5 Commissioning and Application
Examples

5.1 Commissioning

5.1.1 Quick Menu Mode

Parameter Data
The graphical display (GLCP) provides access to all parameters
listed under the Quick Menus. The numeric display (NLCP) only
provides access to the Quick Setup parameters. To set parame-
ters using the [Quick Menu] button - enter or change parame-
ter data or settings in accordance with the following
procedure:
1. Press Quick Menu button
▲ ▼
2.
Use the [ ] and [ ] buttons to find the parameter
you want to change
3. Press [OK]
▲ ▼
4.
Use [ ] and [ ] buttons to select the correct parame-
ter setting
5. Press [OK]
6. To move to a different digit within a parameter
◀
setting, use the [ ] and [
7. Highlighted area indicates digit selected for change
8. Press [Cancel] button to disregard change, or press
[OK] to accept change and enter the new setting
Example of changing parameter data
Assume parameter 22-60 is set to [Off]. However, you want to
monitor the fan-belt condition - non- broken or broken -
according to the following procedure:
1. Press Quick Menu key
2.
Choose Function Setups with the [
3. Press [OK]
4.
Choose Application Settings with the [
5. Press [OK]
6. Press [OK] again for Fan Functions
7. Choose Broken Belt Function by pressing [OK]
▼
8.
With [ ] button, choose [2] Trip
The frequency converter will now trip if a broken fan-belt is
detected.
®
VLT HVAC Drive Operating Instructions
▶
] buttons
▼
] button
▼
] button
®
MG.11.AD.02 - VLT is a registered Danfoss trademark
Select [My Personal Menu] to display personal parameters:
For example, an AHU or pump OEM may have pre-program-
med personal parameters to be in My Personal Menu during
factory commissioning to make on-site commissioning/fine
tuning simpler. These parameters are selected in par. 0-25 My
Personal Menu. Up to 20 different parameters can be program-
med in this menu.
Select [Changes Made] to get information about:
•
The last 10 changes. Use the up/down navigation
keys to scroll between the last 10 changed parame-
ters.
•
The changes made since default setting.
Select [Loggings]:
to get information about the display line read-outs. The
information is shown as graphs.
Only display parameters selected in par. 0-20 Display Line 1.1
Small and par. 0-24 Display Line 3 Large can be viewed. It is
possible to store up to 120 samples in the memory for later
reference.
Quick Setup
Efficient Parameter Set-up for VLT HVAC Drive Applications:
The parameters can easily be set up for the vast majority of
the VLT HVAC Drive applications only by using the [Quick
Setup] option.
After pressing [Quick Menu], the different choices in the Quick
Menu are listed. See also illustration 6.1 below and tables Q3-1
to Q3-4 in the followingFunction Setups section.
Example of using the Quick Setup option:
Assume you want to set the Ramp Down Time to 100 seconds:
1. Select [Quick Setup]. The first par. 0-01 Language in
Quick Setup appears
▼
2.
Press [ ] repeatedly until par. 3-42 Ramp 1 Ramp
Down Time appears with the default setting of 20
seconds
3. Press [OK]
◀
4.
Use the [ ] button to highlight the 3rd digit before
the comma
5.
Change '0' to '1' by using the [
▶
6.
Use the [ ] button to highlight the digit '2'
7.
Change '2' to '0' with the [
8. Press [OK]
The new ramp-down time is now set to 100 seconds.
It is recommended to do the set-up in the order listed.
▲
] button
▼
] button
