Introduction
1.1.5 Type Code String low and medium
power
Description
Product group & FC Series
Power rating
Number of phases
Mains voltage
Enclosure
RFI filter
Brake
Display
Coating PCB
Mains option
Adaptation
Adaptation
Software release
Software language
A options
B options
C0 options MCO
®
VLT HVAC Drive Operating Instructions
Pos Possible choice
1-6 FC 102
8-10 1.1- 90 kW (P1K1 - P90K)
11 Three phases (T)
T 2: 200-240 VAC
11-12 T 4: 380-480 VAC
T 6: 525-600 VAC
E20: IP20
E21: IP 21/NEMA Type 1
E55: IP 55/NEMA Type 12
13-15
E66: IP66
P21: IP21/NEMA Type 1 w/backplate
P55: IP55/NEMA Type 12 w/backplate
H1: RFI filter class A1/B
H2: RFI filter class A2
16-17
H3: RFI filter class A1/B (reduced cable length)
Hx: No RFI filter
X: No brake chopper included
B: Brake chopper included
18
T: Safe Stop
U: Safe + brake
G: Graphical Local Control Panel (GLCP)
19 N: Numeric Local Control Panel (NLCP)
X: No Local Control Panel
X. No coated PCB
20
C: Coated PCB
X: No Mains disconnect switch and Load Sharing
1: With Mains disconnect switch (IP55 only)
21 8: Mains disconnect and Load Sharing
D: Load Sharing
See Chapter 8 for max. cable sizes.
X: Standard
22
0: European metric thread in cable entries.
23 Reserved
24-27 Actual software
28
AX: No options
A0: MCA 101 Profibus DP V1
29-30 A4: MCA 104 DeviceNet
AG: MCA 108 Lonworks
AJ: MCA 109 BACnet gateway
BX: No option
BK: MCB 101 General purpose I/O option
31-32
BP: MCB 105 Relay option
BO: MCB 109 Analog I/O option
33-34 CX: No options
®
