DC Filters
Design Guide

7 Specifications

7.1 General Specifications

Table 7: General Specifications for DC Filters
Item
Nominal voltage
Switching frequency
Power loss
Overload capacity
Protection level
Insulation class
Standards

7.2 Environmental Data

Table 8: Environmental Data for the DC Filters
Item
Temperature during operation
Temperature during storage and transportation
Relative humidity (during operation)
Pollution degree (EN61800-5-1)
Air quality
Contamination levels (IEC 60721-3-3)
Altitude (during operation)
Danfoss A/S © 2023.01
Specification
750 V DC (Voltage range: 0–1200 V DC)
1025 V DC (Voltage range: 0–1200 V DC)
5 kHz
See 7.4 Technical Data
1.5 x I 1 min overload/10 min total cycle, RMS = I
NOM
IP00
Class H (180 °C)
IEC61800-5-1, UL61800-5-1
REACH, RoHS 3, China RoHS, IEC 62474
IEC60721-3-3
IEC60076-6
UL 1741
Specification
-10...+50 °C, full performance
+50...+60 °C, limited performance
Current derating of 2% for each increased degree Celsius.
-40...+70 °C
0–95%, no condensation
PD 3
Chemically active substances: 3C2
Mechanically active substances: 3S2
Maximum 2000 m above sea level.
Current derating according to equivalent DC/DC converter.
overcycle
NOM
AJ377845348678en-000101 / 172F4785 | 17
