Profibus - Danfoss FC 100 Series Operating Instructions Manual

How to Programme the Frequ...

7.3.10 9-** Profibus

Par. No. # Parameter description
9-00 Setpoint
9-07 Actual Value
9-15 PCD Write Configuration
9-16 PCD Read Configuration
9-18 Node Address
9-22 Telegram Selection
9-23 Parameters for Signals
9-27 Parameter Edit
9-28 Process Control
9-44 Fault Message Counter
9-45 Fault Code
9-47 Fault Number
9-52 Fault Situation Counter
9-53 Profibus Warning Word
9-63 Actual Baud Rate
9-64 Device Identification
9-65 Profile Number
9-67 Control Word 1
9-68 Status Word 1
9-71 Profibus Save Data Values
9-72 ProfibusDriveReset
9-80 Defined Parameters (1)
9-81 Defined Parameters (2)
9-82 Defined Parameters (3)
9-83 Defined Parameters (4)
9-84 Defined Parameters (5)
9-90 Changed Parameters (1)
9-91 Changed Parameters (2)
9-92 Changed Parameters (3)
9-93 Changed Parameters (4)
9-94 Changed Parameters (5)
®
VLT HVAC Drive Operating Instructions
Default value
0 N/A
0 N/A
SR
SR
126 N/A
[108] PPO 8
0
[1] Enabled
[1] Enable cyclic master
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
[255] No baudrate found
0 N/A
0 N/A
0 N/A
0 N/A
[0] Off
[0] No action
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
®
MG.11.AD.02 - VLT is a registered Danfoss trademark
4-set-up Change during
operation sion index
All set-ups TRUE
All set-ups FALSE
2 set-ups TRUE
2 set-ups TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
2 set-ups FALSE
2 set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
Conver- Type
0 Uint16
0 Uint16
- Uint16
- Uint16
0 Uint8
- Uint8
- Uint16
- Uint16
- Uint8
0 Uint16
0 Uint16
0 Uint16
0 Uint16
7
0 V2
- Uint8
0 Uint16
0 OctStr[2]
0 V2
0 V2
- Uint8
- Uint8
0 Uint16
0 Uint16
0 Uint16
0 Uint16
0 Uint16
0 Uint16
0 Uint16
0 Uint16
0 Uint16
0 Uint16
105
7
