VLT AutomationDrive FC 300 Operating
Instructions

5 General Specifications

Mains supply (L1, L2, L3):
Supply voltage
Supply voltage
Supply voltage
Mains voltage low / mains drop-out:
During low mains voltage or a mains drop-out, the FC continues until the intermediate circuit voltage drops below the minimum stop level, which
corresponds typically to 15% below the frequency converter's lowest rated supply voltage. Power-up and full torque cannot be expected at mains voltage
lower than 10% below the frequency converter's lowest rated supply voltage.
Supply frequency
Max. imbalance temporary between mains phases
True Power Factor (λ)
Displacement Power Factor (cos ϕ)
Switching on input supply L1, L2, L3 (power-ups) ≤ 7.5 kW
Switching on input supply L1, L2, L3 (power-ups) 11-75 kW
Switching on input supply L1, L2, L3 (power-ups) ≥ 90 kW
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/500/600/ 690 V maximum.
Motor output (U, V, W):
Output voltage
Output frequency (0.25-75 kW)
Output frequency (90-1000 kW)
Output frequency in Flux Mode (FC 302 only)
Switching on output
Ramp times
* Voltage and power dependent
Torque characteristics:
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
Starting torque (Variable torque)
Overload torque (Variable torque)
*Percentage relates to the nominal torque.
Digital inputs:
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic'0' PNP
Voltage level, logic'1' PNP
Voltage level, logic '0' NPN 2)
Voltage level, logic '1' NPN 2)
Maximum voltage on input
Pulse frequency range
(Duty cycle) Min. pulse width
Input resistance, R
i
3, 5)
Safe stop Terminal 37 (Terminal 37 is fixed PNP logic):
Voltage level
Voltage level, logic'0' PNP
Voltage level, logic'1' PNP
Nominal input current at 24 V
®
MG.33.AG.02 - VLT is a registered Danfoss trademark
5 General Specifications
200-240 V ±10%
FC 301: 380-480 V / FC 302: 380-500 V ±10%
FC 302: 525-600 V ±10%
FC 302: 525-690 V ±10%
50/60 Hz ±5%
3.0 % of rated supply voltage
≥ 0.9 nominal at rated load
near unity (> 0.98)
maximum 2 times/min.
maximum 1 time/min.
maximum 1 time/2 min.
overvoltage category III/pollution degree 2
0 - 100% of supply voltage
FC 301: 0.2 - 1000 Hz / FC 302: 0 - 1000 Hz
0 - 800* Hz
0 - 300 Hz
0.01 - 3600 sec.
maximum 160% for 60 sec.
maximum 180% up to 0.5 sec.
maximum 160% for 60 sec.
maximum 110% for 60 sec.
maximum 110% for 60 sec.
FC 301: 4 (5) 1) / FC 302: 4 (6)
1)
18, 19, 27 , 29
PNP or NPN
0 - 24 V DC
> 10 V DC
> 19 V DC
< 14 V DC
0 - 110 kHz
approx. 4 kΩ
0 - 24 V DC
50 mA rms
5
Unlimited
*
*
*
*
1)
1)
, 32, 33,
< 5 V DC
28 V DC
4.5 ms
< 4 V DC
>20 V DC
95
