7.3.9 8-** Communication and Options

Par. No. # Parameter description
8-0* General Settings
8-01 Control Site
8-02 Control Source
8-03 Control Timeout Time
8-04 Control Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Timeout
8-07 Diagnosis Trigger
8-1* Control Settings
8-10 Control Profile
8-13 Configurable Status Word STW
8-3* FC Port Settings
8-30 Protocol
7 7
8-31 Address
8-32 Baud Rate
8-33 Parity / Stop Bits
8-34 Estimated cycle time
8-35 Minimum Response Delay
8-36 Maximum Response Delay
8-37 Maximum Inter-Char Delay
8-4* FC MC protocol set
8-40 Telegram Selection
8-42 PCD write configuration
8-43 PCD read configuration
8-5* Digital/Bus
8-50 Coasting Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
8-55 Set-up Select
8-56 Preset Reference Select
8-7* BACnet
8-70 BACnet Device Instance
8-72 MS/TP Max Masters
8-73 MS/TP Max Info Frames
8-74 "I-Am" Service
8-75 Initialisation Password
8-8* FC Port Diagnostics
8-80 Bus Message Count
8-81 Bus Error Count
8-82 Slave Messages Rcvd
8-83 Slave Error Count
8-84 Slave Messages Sent
8-85 Slave Timeout Errors
8-89 Diagnostics Count
8-9* Bus Jog / Feedback
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
8-94 Bus Feedback 1
8-95 Bus Feedback 2
8-96 Bus Feedback 3
104
®
VLT HVAC Drive Operating Instructions
Default value
null
null
SR
[0] Off
[1] Resume set-up
[0] Do not reset
[0] Disable
[0] FC profile
[1] Profile Default
null
SR
null
null
0 ms
SR
SR
SR
[1] Standard telegram 1
SR
SR
[3] Logic OR
[3] Logic OR
[3] Logic OR
null
[3] Logic OR
[3] Logic OR
1 N/A
127 N/A
1 N/A
[0] Send at power-up
SR
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
100 RPM
200 RPM
0 N/A
0 N/A
0 N/A
®
MG.11.AD.02 - VLT is a registered Danfoss trademark
4-set-up Change during
operation sion index
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
2 set-ups TRUE
All set-ups FALSE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
2 set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
Conver- Type
- Uint8
- Uint8
-1 Uint32
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint8
- Uint8
- Uint8
-3 Uint32
-3 Uint16
-3 Uint16
-5 Uint16
- Uint8
- Uint16
- Uint16
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint32
0 Uint8
0 Uint16
- Uint8
0 VisStr[20]
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Int32
67 Uint16
67 Uint16
0 N2
0 N2
0 N2
