Troubleshooting
WARNING/ALARM 34, Fieldbus communication fault
The fieldbus on the communication option card is not
working.
WARNING/ALARM 35, Out of frequency range:
This warning is active if the output frequency has reached the
high limit (set in par. 4-53) or low limit (set in par. 4-52). In
Process Control, Closed Loop (par. 1-00) this warning is
displayed.
WARNING/ALARM 36, Mains failure
This warning/alarm is only active if the supply voltage to the
frequency converter is lost and par. 14-10 Mains Failure is NOT
set to OFF. Check the fuses to the frequency converter
ALARM 38, Internal fault
It may be necessary to contact your Danfoss supplier. Some
typical alarm messages:
0 Serial port cannot be initialized. Serious hardware failure
256-258 Power EEPROM data is defect or too old
512 Control board EEPROM data is defect or too old
513 Communication time out reading EEPROM data
8 8
514 Communication time out reading EEPROM data
515 Application Orientated Control cannot recognize the
EEPROM data
516 Cannot write to the EEPROM because a write command
is on progress
517 Write command is under time out
518 Failure in the EEPROM
519 Missing or invalid Barcode data in EEPROM
783 Parameter value outside of min/max limits
1024- A can-telegram that has to be sent, couldn't be sent
1279
1281 Digital Signal Processor flash timeout
1282 Power micro software version mismatch
1283 Power EEPROM data version mismatch
1284 Cannot read Digital Signal Processor software version
1299 Option SW in slot A is too old
1300 Option SW in slot B is too old
1302 Option SW in slot C1 is too old
1315 Option SW in slot A is not supported (not allowed)
1316 Option SW in slot B is not supported (not allowed)
1318 Option SW in slot C1 is not supported (not allowed)
1379 Option A did not respond when calculating Platform
Version.
1380 Option B did not respond when calculating Platform
Version.
1536 An exception in the Application Orientated Control is
registered. Debug information written in LCP
1792 DSP watchdog is active. Debugging of power part data
Motor Orientated Control data not transferred correctly
2049 Power data restarted
2064-2072 H081x: option in slot x has restarted
2080-2088 H082x: option in slot x has issued a powerup-wait
2096-2104 H083x: option in slot x has issued a legal powerup-wait
130
®
VLT HVAC Drive Operating Instructions
2304
2305
2314
2315
2316
2324
2330
2561
2562
2816
2817
2818
2819
2820
2821
2822
2836
3072-5122 Parameter value is outside its limits
5123
5124
5125
5126
5376-6231 Out of memory
ALARM 39, Heatsink sensor
No feedback from the heatsink temperature sensor.
The signal from the IGBT thermal sensor is not available on the
power card. The problem could be on the power card, on the
gate drive card, or the ribbon cable between the power card
and gate drive card.
WARNING 40, Overload of Digital Output Terminal 27
Check the load connected to terminal 27 or remove short-
circuit connection. Check par. 5-00 Digital I/O Mode and
par. 5-01 Terminal 27 Mode.
WARNING 41, Overload of Digital Output Terminal 29
Check the load connected to terminal 29 or remove short-
circuit connection. Check par. 5-00 Digital I/O Mode and
par. 5-02 Terminal 29 Mode.
WARNING 42, Overload of Digital Output on X30/6 or Overload
of Digital Output on X30/7
For X30/6, check the load connected to X30/6 or remove
short-circuit connection. Check par. 5-32 Term X30/6 Digi Out
(MCB 101).
For X30/7, check the load connected to X30/7 or remove
short-circuit connection. Check par. 5-33 Term X30/7 Digi Out
(MCB 101).
®
MG.11.AD.02 - VLT is a registered Danfoss trademark
Could not read any data from power EEPROM
Missing SW version from power unit
Missing power unit data from power unit
Missing SW version from power unit
Missing io_statepage from power unit
Power card configuration is determined to be incorrect
at power up
Power size information between the power cards does
not match
No communication from DSP to ATACD
No communication from ATACD to DSP (state running)
Stack overflow Control board module
Scheduler slow tasks
Fast tasks
Parameter thread
LCP Stack overflow
Serial port overflow
USB port overflow
cfListMempool to small
Option in slot A: Hardware incompatible with Control
board hardware
Option in slot B: Hardware incompatible with Control
board hardware
Option in slot C0: Hardware incompatible with Control
board hardware
Option in slot C1: Hardware incompatible with Control
board hardware
