Electrical Installation
4
4
Illustration 4.13: How to connect to mains and earthing
30
®
VLT
HVAC Drive Operating Instructions
for C1 and C2.
MG.11.AD.02 - VLT
4.1.10 Mains Connection for C3 and C4
Illustration 4.14: How to connect C3 to mains and
Illustration 4.15: How to connect C4 to mains and
®
is a registered Danfoss trademark
earthing.
earthing.
