6-26 Terminal 54 Filter Time Constant
Range: Function:
0.001 s [0.001 - Enter the time constant. This is a first-order
*
10.000 s] digital low pass filter time constant for
suppressing electrical noise in terminal 54.
A high time constant value improves
dampening but also increases the time
delay through the filter.
This parameter cannot be adjusted while
the motor is running.
6-27 Terminal 54 Live Zero
Option: Function:
This parameter makes it possible to disable the Live
Zero monitoring. E.g. to be used if the analog
outputs are used as part of a de-central I/O system
(e.g. when not as part of any frequency converter
related control functions, but feeding a Building
Management System with data).
[0] Disabled
[1] Enabled
*
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an
analog current output. A motor current
of 20 mA corresponds to I
[0] No operation
*
[100] Output freq. 0 - 100 Hz, (0-20 mA)
0-100
[101] Reference Min- Minimum reference - Maximum
Max reference, (0-20 mA)
[102] Feedback +-200% -200% to +200% of
par. 20-14 Maximum Reference/Feedb.,
(0-20 mA)
[103] Motor cur. 0-Imax 0 - Inverter Max. Current (par. 16-37 Inv.
Max. Current), (0-20 mA)
[104] Torque 0-Tlim 0 - Torque limit (par. 4-16 Torque Limit
Motor Mode), (0-20 mA)
[105] Torque 0-Tnom 0 - Motor rated torque, (0-20 mA)
[106] Power 0-Pnom 0 - Motor rated power, (0-20 mA)
[107] Speed 0-HighLim 0 - Speed High Limit (par. 4-13 Motor
*
Speed High Limit [RPM] and
par. 4-14 Motor Speed High Limit [Hz]),
(0-20 mA)
[113] Ext. Closed Loop 0 - 100%, (0-20 mA)
1
[114] Ext. Closed Loop 0 - 100%, (0-20 mA)
2
[115] Ext. Closed Loop 0 - 100%, (0-20 mA)
3
[130] Out frq 0-100 0 - 100 Hz
4-20mA
®
VLT HVAC Drive Operating Instructions
6-50 Terminal 42 Output
Option:
[131]
[132]
[133]
[134]
[135]
[136]
[137]
[139]
[140]
[141]
[142]
[143]
[144]
[145]
.
max
NOTE
Values for setting the Minimum Reference is found in
open loop par. 3-02 Minimum Reference and for closed
loop par. 20-13 Minimum Reference/Feedb. - values for
maximum reference for open loop is found in
par. 3-03 Maximum Reference and for closed loop
par. 20-14 Maximum Reference/Feedb..
6-51 Terminal 42 Output Min Scale
Range:
0.00 %
®
MG.11.AD.02 - VLT is a registered Danfoss trademark
Function:
Reference Minimum Reference - Maximum
4-20mA Reference
Feedback 4-20mA -200% to +200% of
par. 20-14 Maximum Reference/Feedb.
Motor cur. 0 - Inverter Max. Current (par. 16-37 Inv.
4-20mA Max. Current)
Torq.0-lim 4-20 0 - Torque limit (par. 4-16 Torque Limit
mA Motor Mode)
Torq.0-nom 0 - Motor rated torque
4-20mA
Power 4-20mA 0 - Motor rated power
Speed 4-20mA 0 - Speed High Limit (4-13 and 4-14)
Bus ctrl. 0 - 100%, (0-20 mA)
Bus ctrl. 4-20 mA 0 - 100%
Bus ctrl t.o. 0 - 100%, (0-20 mA)
Bus ctrl t.o. 0 - 100%
4-20mA
Ext. CL 1 4-20mA 0 - 100%
Ext. CL 2 4-20mA 0 - 100%
Ext. CL 3 4-20mA 0 - 100%
Function:
[0.00 - Scale for the minimum output (0 or 4 mA)
*
200.00 %] of the analogue signal at terminal 42.
Set the value to be the percentage of the
full range of the variable selected in
par. 6-50 Terminal 42 Output.
