0-20 Display Line 1.1 Small
Option:
[2230] No-Flow Power The calculated No Flow Power for the
[2316] Maintenance
Text
[2580] Cascade Status Status for the operation of the Cascade
[2581] Pump Status
[3110] Bypass Status
Word
[3111] Bypass
Running Hours
[9913] Idle time
7 7
[9914] Paramdb
requests in
queue
[9920] HS Temp. (PC1)
[9921] HS Temp. (PC2)
[9922] HS Temp. (PC3)
[9923] HS Temp. (PC4)
[9924] HS Temp. (PC5)
[9925] HS Temp. (PC6)
[9926] HS Temp. (PC7)
[9927] HS Temp. (PC8)
NOTE
Please consult the VLT HVAC Drive Programming Guide,
MG.11.CX.YY for detailed information.
0-21 Display Line 1.2 Small
Select a variable for display in line 1, middle position.
Option:
[1614] Motor Current The options are the same as those listed
*
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position.
Option:
[1610] Power [kW] The options are the same as those listed in
*
0-23 Display Line 2 Large
Select a variable for display in line 2.
Option:
[1613] Frequency The options are the same as those listed in
*
68
®
VLT
Function:
actual operating speed
Controller
Status for the operation of each individ-
ual pump controlled by the Cascade
Controller
Function:
in par. 0-20 Display Line 1.1 Small.
Function:
par. 0-20 Display Line 1.1 Small.
Function:
par. 0-20 Display Line 1.1 Small.
MG.11.AD.02 - VLT
HVAC Drive Operating Instructions
0-24 Display Line 3 Large
Select a variable for display in line 3.
Option:
[1502] kWh Counter The options are the same as those listed in
*
0-37 Display Text 1
Range: Function:
0 [0 - In this parameter it is possible to write an individual text
*
0 ] string for display in the LCP or to be read via serial
communication. If to be displayed permanently select
Display Text 1 in par. 0-20 Display Line 1.1 Small,
par. 0-21 Display Line 1.2 Small, par. 0-22 Display Line 1.3
Small, par. 0-23 Display Line 2 Large or par. 0-24 Display
Line 3 Large. Use the [
change a character. Use the [
move the cursor. When a character is highlighted by the
cursor, it can be changed. Use the [
the LCP to change a character. A character can be
inserted by placing the cursor between two characters
and pressing [
0-38 Display Text 2
Range: Function:
0 [0 - In this parameter it is possible to write an individual text
*
0 ] string for display in the LCP or to be read via serial
communication. If to be displayed permanently select
Display Text 2 in par. 0-20 Display Line 1.1 Small,
par. 0-21 Display Line 1.2 Small, par. 0-22 Display Line 1.3
Small, par. 0-23 Display Line 2 Large or par. 0-24 Display
Line 3 Large. Use the [
change a character. Use the [
move the cursor. When a character is highlighted by the
cursor, this character can be changed. A character can
be inserted by placing the cursor between two charac-
ters and pressing [
0-39 Display Text 3
Range: Function:
0 [0 - In this parameter it is possible to write an individual text
*
0 ] string for display in the LCP or to be read via serial
communication. If to be displayed permanently select
Display Text 3 in par. 0-20 Display Line 1.1
Small,par. 0-21 Display Line 1.2 Small, par. 0-22 Display
Line 1.3 Small, par. 0-23 Display Line 2 Large or
par. 0-24 Display Line 3 Large. Use the [
on the LCP to change a character. Use the [
buttons to move the cursor. When a character is
highlighted by the cursor, this character can be
changed. A character can be inserted by placing the
cursor between two characters and pressing [
®
is a registered Danfoss trademark
Function:
par. 0-20 Display Line 1.1 Small.
▲ ▼
] or [ ] buttons on the LCP to
◀ ▶
] and [ ] buttons to
▲ ▼
] or [ ] buttons on
▲ ▼
] or [ ].
▲ ▼
] or [ ] buttons on the LCP to
◀ ▶
] and [ ] buttons to
▲ ▼
] or [ ].
▲ ▼
] or [
◀
] and [
▲
] buttons
▶
]
▼
] or [ ].
