P r i n t e r S p e c i f i c a t i o n s

Ribbon Specifications

Ribbon width:
2" Printer: 2.4" (61mm) Max.
2" Nominal Length: 6500" (approx. 165m) Max.
4" Printer: 4.25" (108mm) Max.
4" Nominal Length: 6500" (approx. 140m) Max.
Types: Available in Wax, Wax/Resin, and Premium Resin varieties

Label Roll Changes per Ribbon

Label Roll OD
5"
7"
7" Label Roll OD = equivalent to 8" Roll

Font Specifications

Bitmapped: 7 styles with up to 10x10 magnification, variable boldness and spacing.
International AGFA Fonts: Sans-serif font in 7 pt. sizes, up to 4x4 magnification, vari-
able boldness and spacing.
Scalable Vector Fonts: 3 ultra font styles for smooth characters in any size and bold-
ness.
Rotations: 0, 90, 180, 270 degrees
9-4
Label Roll ID
1.5"
1.5"
2" Label Rolls per
Ribbon Roll
2.4
1
4" Label Rolls per
Ribbon Roll
2
.85
