C l e a n i n g a n d P r e v e n t i v e M a i n t e n a n c e

Platen Assembly Replacement

NOTE: If the printer is within the warranty period, the user must must contact
an authorized repair center or authorized field technician. All user's must not
replace the printhead assembly or platen assembly if the printer in under war-
ranty.
1. During installation of the platen, note the small diameter of the platen bearing snap
feature. That area goes down into the platen bearing snaps.
2. Slightly bias the enclosure away from the left side of the platen. Slide the left side of
the platen into its plastic snap.
11-12
