G e t t i n g S t a r t e d

Loading Media

All printers have media loading instruction labels on the bottom of the dust cover.
To increase the life of the printhead, we recommend using media approved by the manu-
facturer with all printer models. The printhead warranty requires approved media. For
more information regarding approved media please contact a local reseller or the manu-
facturer
1. Lift the top dust cover (Thermal Transfer printers have already completed this step
in the ribbon loading section).
2. Remove the Manufacturing Test Sample from inside the printer and file the Manu-
facturing Test Sample with the other documentation for future reference (Thermal
Transfer printers have already completed this step in the ribbon loading section).
Figure 2-38: Removing the Manufacturing Test Sample from the Printer
2-32
Figure 2-37: Lifting the Dust Cover
