G e t t i n g S t a r t e d

Controls, Indicators, and Connectors

Controls and indicators for the printer are located on the front panel and right side of the
printer. 7008 printers also have an LCD display on the user interface.
Device
A – POWER light
B – READY indicator
C – FEED button
D – ON/OFF switch
2-14
Figure 2-12: Printer Controls and Indicators
Primary Function
Shows power status
Shows printer status
Advances print media
Controls printer power
Use
ON – printer on and ready to print
OFF – no power applied
GREEN – printer ready to accept data
RED – printer error, empty media roll, or paused
operation during batch mode processing
OFF – no power applied
Press to advance media
Press and hold while turning unit on to initiate self test
and print current configuration
Press to turn printer on and off
