Printhead Assembly (TPH, Shield, Bracket, and LED Array)

Platen and Index Sensor

Components Description
A Index Sensor
B Platen
Figure 2-8: Printhead Assembly
Figure 2-9: Platen Assembly and Index Sensor
G e t t i n g S t a r t e d
2-7
