Take Up Spindle and Take Up Clutch (Gears)

Figure 2-6: Take Up Spindle, Clutch, and Side view of Clutch Gears
Components Description
A Take Up Spindle
B Take Up Clutch

Supply Spindle and Supply Clutch

Components Description
A Supply Spindle
B Supply Clutch
2-6
Figure 2-7: Supply Spindle and Clutch
