The print ribbon cartridge is ready to be replaced in the printer.

Replacing the print ribbon cartridge

When replacing the print ribbon cartridge, begin with the top cover open.
Replace the print ribbon cartridge
1
2
Place the full supply roll on the right spool holder (step 1 in
Place the empty take-up spool on the left spool holder (step 3 in
the ribbon in front of the glide rollers (step 2 in
Take-up spool
3
Figure 4-3: Load print ribbon in the cartridge
Press on the spools and turn them slightly (if needed) until the spools click into
place. Make sure the ribs inside the spool align with the grooves in the spool
holder.
Pick up the cartridge and turn the ribbon take-up knob (with the empty spool) to
remove slack from the print ribbon.
Hold the loaded print ribbon cartridge by the handle over the print station.
Align the print ribbon cartridge so the ribbon spools are over the print ribbon
spindles (step 1 in Figure
Figure
New supply ribbon
Glide rollers
2
Ribbon take-up knob
♦
4-4).
User's Guide for the ImageCard® IV Printer
Loading supplies
Figure 4-3).
Figure 4-3), with
4-3).
