Unlocking The Cover - DataCard ImageCard IV User Manual

3-4
Connect the power cord
1
2
E

Unlocking the cover

If your printer has an optional locking cover, follow this procedure to unlock the cover.
The printer might be unlocked for shipping.
Unlock the cover
1
2
Verify that serial port settings are correct using the steps in
page C-1.
Attach the power cord to the power receptacle on the back of the printer (step 1 in
Figure 3-3).
ICIV052U
Figure 3-3: Attach the power cord
Plug the other end of the power cord into a single phase,
3-wire grounded receptacle with 90-130V AC or 195-254V AC at 50 or 60 Hz (step
2 in Figure 3-3).
The printer power supply automatically adjusts to the voltage of the input power.
Insert the key into the lock (step 1 in
way.
Push down and turn the keylock one-quarter turn clockwise
(step 2 in Figure 3-4).
♦
2
1
♦
Figure 3-4). The key fits the lock only one
User's Guide for the ImageCard® IV Printer
Setting up the printer
"PC port settings" on
to open the lock
