Maintaining the printer
4
5
i
i
User's Guide for the ImageCard® IV Printer
iciv179u
Figure 7-17: Pass the connector through the printhead cage
Lift the printhead cage to move it to the resting position.
Grasp the printhead and align the side pins with the clips in the printhead cage.
Press firmly on the ribbed side of the printhead (step 1 in
the flat side (step 2 in Figure
Make sure both side pins are firmly seated in the clips.
Figure 7-18: Replace the printhead in the cage
If the printhead does not look similar to
the printhead cartridge might be backward.
2
1
7-18) in until the pins are firmly seated in the clips.
1
Side pin
2
Figure 7-18
3
Figure 7-18) and then
Side pin
Clip
iciv088u
or does not snap into place,
7-19
