10 Lift the label on the supply roll and unroll about 8 inches from the supply roll.
11 Wind the supply material in front of the guides and around the take-up spool (step
12 Press the label onto the take-up spool to secure the supply material (step 4 in
13 If your cartridge includes spool caps, press the spool caps back into position on
14 Pick up the supply cartridge and turn it over. Turn the take-up knob clockwise
The supply cartridge is ready to be replaced in the printer.

Replacing the supply cartridge

When replacing the supply cartridge, begin with the top cover open.
Replace the overlay cartridge
1
2
3 in Figure 4-9). Make sure that the material will wind counterclockwise
Figure 4-9).
the ends of the take-up spool and supply roll (step 5 in
E
If you use an adjustable overlay cartridge, do not use spool caps. They
interfere with the operation of the adjustable overlay cartridge.
to remove any slack in the supply material.
E
Make sure the supply tracker is out of the way when you replace the overlay
cartridge.
!
When the top cover opens, the interlock switch removes power to all motors
and fans. Power is removed from the heater in the overlay (and topcoat)
stations. Overlay (and topcoat) stations remain HOT.
Hold the loaded overlay cartridge over the overlay station.
E
If you have more than one optional station, make sure you match the cartridge
with the station.
Align the overlay cartridge so the spools in the cartridge are over the spindles in
the station.
Figure
User's Guide for the ImageCard® IV Printer
Loading supplies
.
4-9).
