B-6

Topcoat material

Use Datacard-approved topcoat material in the ImageCard IV printer, if the printer
includes an optional topcoat station. The following describes the topcoat supply to
use:
i
Name
"Genuine Authentic"
holographic topcoat
Clear topcoat
Tips for success
•
•
•

Supply roll storage

Follow these guidelines when storing supply rolls:
•
•
•
•
•
If the printer has an optional overlay station, see
Part number
557104-500
557105-001
Topcoat material covers the full surface of the card. You cannot use the topcoat
station to apply topcoat in selected areas of the card.
Clear or holographic topcoat can be applied to contactless (RF) smart cards.
To apply topcoat to selected areas of a card, such as around a magnetic stripe or
contacted smart card, use a print ribbon with a topcoat (T) panel, such as YMCKT.
Choose print blocking in the SmartDriver so topcoat is not applied over the
magnetic stripe, smart card chip or other feature.
The print ribbon, topcoat and laminate supply rolls maintain their quality for about
a year. For optimal card quality, purchase and store quantities that you can use up
in less than a year.
The print ribbon, card stock, and laminator supply might require secure storage
and tracking. Follow your policy for storing and tracking the supplies used to make
cards.
Select a location away from direct sunlight and heat sources, with a temperature
between 32° F and 77° F or between 0° C and 25° C. A humidity range from 40%
to 60% (non-condensing) is recommended.
Supply rolls should be at room temperature when they are installed in the printer
and used. If supplies are stored in a cooler environment than the printer, allow
supplies to reach room temperature before using.
If the printer will not be used for an extended period of time, remove supplies from
the printer and store them with your supplies inventory.
"Laminate material" on page
Description
Single roll of continuous topcoat
for about 625 cards.
Single roll of continuous topcoat
for about 625 cards.
User's Guide for the ImageCard® IV Printer
B-4.
