Clean The Inside Of The Printer - DataCard ImageCard IV User Manual

7-6
i
i
Tools to use:
•
•
•

Clean the inside of the printer

1
2
3
Topcoat supply material can release small particles as the material is used.
Particles accumulate around the lower card track and other horizontal surfaces.
Particles also can stick to cards or rollers.
Holographic topcoat particles are easy to see, while clear topcoat particles are not
as visible. Some supply lots will release more particles, called flash, than other
lots. Adjust your cleaning practices to suit the current supply lot.
Vacuum cleaner with attachments
Clean, lint-free cloth
ImageCard IV cleaning card
Turn off the power to the printer. Remove the power cord from the receptacle.
Unlock the printer if needed.
Push down on the corner of the printer's top cover to unlatch it. Lift the top cover
to the fully upright position.
Remove all supply cartridges. See
information.
! When the top cover opens, the interlock switch removes power to all motors
and fans. If overlay or topcoat stations are installed, power is removed from
the heaters. Overlay or topcoat stations remain HOT.
ICIV067U
Figure 7-3: Clean the inside of the printer
"Loading supplies" on page 4-1
`
User's Guide for the ImageCard® IV Printer
Maintaining the printer
for more
