Packing the printer for shipping

When service requests that you return the printer to a service center for repair, pack
the printer for shipping. You might also need to pack the printer to send it to another
location.
Pack the printer
1
2
3
4
5
6
Turn off the power to the printer.
Unlock the printer if needed.
Remove the power cord from the printer and power receptacle. Remove the
interface cable and any other cables attached to the printer.
– If you are shipping the printer to use at another location, pack the power cord,
interface cable, and any other cables in the accessories bag.
– If you are shipping the printer for service, do not ship cables with the printer
unless asked to do so.
Remove all cards from the card input and output trays.
If you are shipping the printer for service, remove loose cards from the printer if
possible. Do not ship cards unless asked to do so.
Move the printhead to the lowered position by pushing on the end of the print
station cam plate (step 1 in
the indentation, as shown.
Make sure all supply cartridges are secured in place.
Figure 8-7: Prepare the printhead for shipping
Be sure to place the packaging material between the printhead and the print
ribbon cartridge (step 2 in
Figure 8-7). The white pins should rest at the end of
1
2
ICIV172U
Figure 8-7).
