Maintaining the printer
5
6
7
8
9
10 Select the Clean Printer button on the Printer Toolbox. Click the OK button on the
User's Guide for the ImageCard® IV Printer
Close the printer's top cover and push down to latch it.
Remove the card input tray cover. Hold the tray and latch the card pusher in the
notch on the bottom of the card input tray. Move cards back to rest on the card
pusher.
i
Do not touch the printing surface of the cards.
Peel off the protective paper from the cleaning card.
Figure 7-1: Remove the protective paper from the cleaning card
Place the cleaning card in the card input tray as shown in
end of the card into the pick rollers.
i
Make sure the sticky side of the card is toward the card pusher and the lower
edge of the cleaning card rests on the bottom of the tray.
i
If the card separator is set to pick cards that are thinner than 0.035 inch,
change the card separator setting. See
page 3-8 for more information.
iciv070u
Figure 7-2: Place the cleaning card between the card input guide rollers
At the PC, open the Printer Toolbox if needed by double-clicking the icon in the
lower right corner of the desktop.
message box.
Figure 7-2. Insert the
"Printing thicker or thinner cards" on
7-3
