Installing the bezel

This procedure applies only to 4U server models with non-hot-swap power supplies.
To install the bezel on 4U server models with non-hot-swap power supplies,
complete the following steps.
1. Insert the three tabs on the bezel into the corresponding holes in the front of the
2. Rotate the bezel to the server until it locks securely into place.
3. Reconnect the external cables and power cords; then, turn on the attached

Removing the lower bezel

This procedure applies only to the 5U server model with hot-swap power supplies
(Model name: 2582-F4x).
To access the hard disk drives on the 5U server model with hot-swap power
supplies (Model name: 2582-F4x), you must first remove the lower bezel.
To remove the lower bezel on the 5U server model with hot-swap power supplies
(Model name: 2582-F4x), complete the following steps.
1. Read the safety information that begins on page vii and "Installation guidelines"
2. If you are replacing a non-hot-swap component, turn off the server and all
3. Press the blue-colored release button on the right side of the lower bezel and
server.
devices and turn on the server.
on page 163.
attached devices; then, disconnect all power cords and external cables.
rotate the lower bezel downward to disengage from the chassis.
