IBM System x3100 M4 Type 2582 Problem Determination And Service Manual page 172

Table 8. Parts listing for 4U server models with non-hot-swap power supplies, Type 2582. For the 5U server model
with hot-swap power supplies (Model name: 2582-F4x), please see Table 9.
Index Description
1 Side cover assembly
2 Power supply, 300W
2 Power supply, 350W
3 System board assembly
4 Memory, 1 GB 1Rx8 UDIMM, 1333 MHz, DDR3
4 Memory, 2 GB 1Rx8 UDIMM, 1333 MHz, DDR3
4 Memory, 4 GB 2Rx8 UDIMM, 1333 MHz, DDR3
4 Memory, 2GB 1Rx8 UDIMM, 1600 MHz, DDR3
4 Memory, 4GB 2Rx8 UDIMM, 1600 MHz, DDR3
4 Memory, 8GB 2Rx8 UDIMM, 1600 MHz, DDR3
5 System fan, rear
6 Heat sink
7 Microprocessor, Core i3-2100, 3.1GHz 2C 3MB cache
7 Microprocessor, Xeon E3-1270 3.4GHz 4C 8MB cache
7 Microprocessor, Xeon E3-1280 3.5GHz 4C 8MB cache
7 Microprocessor, Xeon E3-1220 3.1GHz 4C 8MB cache
7 Microprocessor, Xeon E3-1230 3.2GHz 4C 8MB cache
7 Microprocessor, Xeon E3-1260L 2.4GHz 4C 8MB cache
7 Microprocessor, Xeon E3-1220L 2.2GHz 2C 3MB cache
7 Microprocessor, Pentium G850 2.9GHz 2C 3MB cache
7 Microprocessor, Xeon E3-1220v2 3.1GHz 4C 8MB cache
7 Microprocessor, Xeon E3-1270v2 3.5GHz 4C 8MB cache
7 Microprocessor, Xeon E3-1280v2 3.6GHz 4C 8MB cache
152
IBM System x3100 M4 Type 2582: Problem Determination and Service Guide
5
4
3
2
7
6
1
10
8
CRU part CRU part
number number
(Tier 1) (Tier 2)
81Y7471
00J6072
00J6073
44T1572
44T1574
44T1575
00D4953
00D4957
00D4961
81Y7481
81Y7493
9
11
FRU part
number
00D8550
69Y5148
69Y5149
81Y6933
81Y6945
81Y6947
81Y6949
81Y6951
81Y7504
00D8552
00D8553
00D8554
