GE 3-Device HDMI Switch Quick Start Manual

3-Device HDMI Switch
®
with Wireless Remote
This 3-Port HDMI ® Switch with remote allows you to easily switch between multiple
HDMI devices while using only one HDMI
instructions entirely before operating your switch.
Features:
• Supports up to 4K UHD resolution
• Supports 3D video
• Connect up to 3 HDMI ® -enabled devices to a single HDMI
• Remote and manually controlled
• Plug-and-play; installs in seconds
Package Contents:
• 3-Port HDMI ® 3D/4K Switch
• Remote Control
• AC/DC 120V Power Adapter
• User Manual
Connecting Your HDMI Enabled Devices to Your 3-Port HDMI
®
1. Connect the HDMI ® cables (not included) from each HDMI
most utilized device on Input 1.
2. Connect an HDMI ® cable from your TV input to the Out port on the back
of the switch.
3. Insert the DC barrel plug into the DC input on the switch.
4. Plug the AC/DC power adapter into a working outlet.
NOTE: Input 1 is the default input when the switch is first powered on. Use only the power
adapter included with this switch.
Connecting Illustration:
4K / HDTV
®
Using Your 3-Port HDMI Switch (Manually):
1. Power on your TV.
2. Power on your 3-Port HDMI ® Switch by pressing the Power/Select button on the
switch (blue LED for Input 1 will illuminate).
3. Power on your HDMI ® -enabled device to be viewed that is connected to the switch.
a. Press the Power/Select button on the HDMI
on your TV; the blue LED will illuminate for the corresponding active input on
the switch.
b. Press the play button to begin viewing the video from your selected device.
4. To power off your switch, press the Power/Select button on the switch until it cycles
through the inputs and the blue LED no longer illuminates an input. The switch is
now powered off.
Using Your 3-Port HDMI ® Switch (Using the Remote):
1. Power on your TV.
2. Press the red Power Button on the remote to power on the switch.
3. Power on your HDMI ® -enabled device to be viewed that is connected to the switch.
4. Press the Input number (1, 2 or 3) on the remote to select the input the device is
connected to. The blue LED will illuminate the input selected and the device should
be displaying on your TV.
5. To turn off your switch, press the red Power Button on the remote. The switch will
turn off and the blue LED will no longer be illuminated.
Installing/Replacing Battery:
1. Turn the remote over and remove the screw at the bottom of the remote.
2. Slide out the battery tray.
3. Install the CR2025 Lithium battery (included) with the positive (+) facing up.
4. Slide the battery tray with the battery back into the remote.
5. Reinstall the screw back into the remote.
Programming GE Universal Remote
• Follow the universal remote instructions manual to program a new device
• Use code 4611
Remote Key Functions:
Key = Power ON/OFF
1
Key = Input 1
2
Key = Input 2
3
Key = Input 3
® input from your display. Please review these
® port
Switch:
®
® device, starting with the
® switch until the device appears
Troubleshooting:
LED is not illuminated on the switch:
• Make sure the AC/DC power supply is plugged into a working outlet
• If AC/DC power adapter is plugged into a surge protector, make sure the surge
protector is powered on
• Make sure the DC plug is plugged completely into the switch
• Make sure the power is turned on, by pressing the Power/Select Button
(Input 1 should be illuminated)
• Unplug and plug the AC/DC power adapter and press the Power/Select Button
(Input 1 should be illuminated)
Has audio but no video:
• Make sure this is not a copied DVD movie, the enabled HDCP protection will block
the copied DVD movie from playing
• Make sure the HDMI
® cable is completely plugged into the DVD player
and the switch
• Make sure the HDMI ® cable is completely plugged into the Out port of the switch
and into the TV's HDMI ® port
• Replace the HDMI ® cable either from the DVD player to the switch or the HDMI
cable from the switch to the TV or replace both cables
Has video but no audio:
• Make sure the volume is turned up on the TV
• Make sure the MUTE function is turned off on the TV
• Replace the HDMI ® cable either from the DVD Player to the switch or the HDMI
cable from the switch to the TV or replace both cables
Remote control does not work:
• Make sure the battery is properly installed with (+) facing upward
• Replace battery
• Make sure all protective film is removed from the remote and switch
• Make sure the remote is pointed at the front of the switch
• Make sure there are no obstructions between the remote and the switch
HDMI switch will not operate manually:
®
• Make sure the AC/DC power adapter is plugged into a working outlet
• Make sure the DC plug is plugged completely into the switch
• Use only the AC/DC power adapter that is included with the switch
• Unplug and plug the AC/DC power adapter from the switch and press the Power/
Select button (Input 1 should be illuminated)
• If the AC/DC power adapter is plugged into a surge protector, make sure the surge
protector is powered on
Glossary:
HDMI ® : High Definition Multimedia Interface
HDCP: High-bandwidth Digital Content Protection is a technology embraced by the
Motion Picture Association of America that eliminates the reproduction of copyrighted
material.
FCC STATEMENT:
Suppliers Declaration of Conformity | Model #: 31046 | Jasco Products Co., 10 E. Memorial Rd,.
Oklahoma City, OK 73114, www.byjasco.com
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
All brand names and products listed/shown are trademarks
or registered trademarks of their respective owners.
The terms HDMI and HDMI High-Definition Multimedia Interface, and
the HDMI Logo are trademarks or registered trademarks of HDMI
Licensing Administrator, Inc. in the United States and other countries.
31046 v2 03/21
MADE IN TAIWAN
GE is a trademark of General Electric Company and is under
license by Jasco Products Company LLC, 10 E. Memorial Rd.,
Oklahoma City, OK 73114.
This Jasco product comes with a limited-lifetime warranty.
Visit www.byjasco.com for warranty details.
Questions? Contact our U.S.-based Consumer Care at
1-800-654-8483 between 7AM-8PM, M-F, Central Time.
®
®
WARNING
• BATTERIES MAY LEAK HARMFUL LIQUIDS
OR IGNITABLE MATERIALS OR EXPLODE
CAUSING INJURY AND PRODUCT DAMAGE
• DO NOT MIX OLD AND NEW OR OTHER
BATTERY TYPES
• REPLACE ALL BATTERIES AT THE SAME TIME
• REPLACE FULLY DISCHARGED BATTERIES
IMMEDIATELY
• REMOVE BATTERIES IF PRODUCT IS TO BE
UNUSED FOR EXTENDED
PERIODS OF TIME
