Canon imagePROGRAF iPF6450 User Manual page 905

iPF6450
Setting Item
Chart
Roll Paper Width
Conserve Paper
Media Type
Print Priority
Print Quality
Extend print pass
Paper Source
Automatic Cutting
Print Labels
7
Configure the color measurement settings and drying
settings, and then click Next.
Setting Item
Color Measurement Preferences
Reduce Drying Time
User's Guide
Selects the color chart to print. If the color chart you want to print is not displayed in the list,
click the Browse button and then select the color chart.
You can only select color charts that are CGATS format RGB.
Click the Acquire Info. button to display the paper width of the roll loaded in the printer.
Selecting this check box allows you to conserve paper by reducing the gap between the pieces
of a color chart when the chart is printed split into pieces.
Select the type of paper.
Choose the graphic elements that you want to emphasize for printing.
For details on the settings, see "Giving Priority to Particular Graphic Elements and Colors for
Printing."
→P.63
Choose the print quality.
For details on the settings, see "Giving Priority to Particular Graphic Elements and Colors for
Printing."
→P.63
Uneven printing may occur when printing with the Highest setting in Print Quality. Selecting
this check box may improve the uneven printing. However, the printing speed will be reduced.
Selects the paper source.
Selects how to cut the paper when Acquire Color Measurement Data finishes.
Select this check box to print the color chart printing information.
Configures the pattern size to print the color charts and the drying settings for the printed color
charts.
Choose Standard to print at the standard pattern size and dry using the standard setting val-
ues.
Click the Settings button to display the Color Measurement Preferences dialog box, which
allows you to configure the pattern size and drying method in detail.
Selecting this check box reduces the drying time.
Once the time configured in the Color Measurement Env. sheet in the Preferences dialog box
has elapsed, color measurement proceeds without performing any further drying with the venti-
lation fan.
Specify a time that offers sufficient drying by air drying in the Preferences dialog box. If you
perform color measurement while the ink is not dry, the measurements may not be correct.
The Preferences dialog box is displayed when you click Preferences in the imagePROGRAF
Color Calibration Management Console menu.
Acquiring Color Measurement Data For Any Color Chart (Mac OS X)
Details
Details
905
