Color Calibration Using the Spectrophotometer Unit (option)
3
Select the White/Black Backing Plate color.
We recommend white.
(See "Switching the White/Black Backing Plate (Optional) Color.")
•
Note
4
Choose the size of the test pattern.
Set Pattern Size in the Control Panel menu.
(See "Menu Settings.")
•
Note
• Executing Color Calibration from the Control Panel on the Printer
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect (Settings/Adj. tab).
•
Note
2
Press the OK button.
Set./Adj. Menu is displayed.
3
Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
4
Press ▲ or ▼ to select Calibration, and then press the OK button.
5
Press ▲ or ▼ to select AutoAdjst(HiPrc) and then press the OK button.
After the environment measurements and paper are confirmed, and color calibration is executed, the adjust-
ment value is set automatically.
Applying Calibration Adjustment Values During Printing
The application of the calibration adjustment values when printing can be set in the printer driver or on the menu of the
Control Panel.
However, when the setting value of the printer driver and the setting value of the Control Panel differ, the setting of the
printer driver is prioritized.
How to Apply
Configure on the printer driver menu. (Windows)
Configure on the printer driver menu. (Mac OS X)
834
Configure on the menu of the Control Panel.
For the color of the White/Black Backing Plate, continue using the selected color without changing each time you
execute color calibration.
→P.663
If you want to prioritize the color measurement precision, it is recommended that you set the Pattern Size to Large.
If the Tab Selection screen is not displayed, press the Menu button.
Configure Calibration Value.
(See "Paper Detailed Settings Dialog Box (Windows).")
Configure Calibration Value.
(See "Paper Detailed Settings Dialog Box (Mac OS X).")
From Set./Adj. Menu, select Adjust Printer > Calibration > Use Adj. Value.
(See "Menu Settings.")
→P.837
How to Operate
→P.189
→P.372
→P.663
