Replacing the Printhead
Important
3
Pull the Printhead Fixer Lever forward all the way to
open it completely.
4
Pull up the Printhead Fixer Cover to open it completely.
932
• Do not touch the Linear Scale (a) or Carriage Shaft (b).
Touching these parts may damage them.
•
Never touch the metal contacts of the Carriage. This may damage the printer.
