Cannot adjust printhead.

Messages regarding printheads

Messages regarding printheads
Cannot adjust printhead. ................................................................................................................................................. 1026

PHeads: wrong pos. ........................................................................................................................................................... 1026

Wrong x printhead. (x is L, R, or not displayed) .................................................................................................... 1026

x printhead error (x is L, R, or not displayed) ......................................................................................................... 1026
Cannot recognize print head x. (x is L, R, or not displayed) ............................................................................. 1027
Execute printhead cleaning. ........................................................................................................................................... 1027
Cannot adjust printhead.
Cannot adjust printhead.
The Printhead nozzles are clogged.
The Printhead cannot be aligned; highly
transparent film is loaded.
PHeads: wrong pos.
PHeads: wrong pos.
Cause
The printheads are installed in the
wrong positions.
Wrong x printhead. (x is L, R, or not displayed)
Wrong x printhead. (x is L, R, or not displayed)
Cause
An incompatible Print-
head has been installed.
x printhead error (x is L, R, or not displayed) x printhead error (x is L, R, or not displayed)
Cause
There is a prob-
lem with the Print-
head.
1026
Cause
Execute Head Posi. Adj. again, as follows.
1.
Press the OK button to clear the error.
2.
Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.")
3.
Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.")
4.
Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors.")
Press the OK button to clear the error.
We recommend using a type of paper that you often use, other than film, for Printhead adjustment.
(See "Automatic Adjustment to Straighten Lines and Colors.")
Open the Top Cover and switch the Printhead used once in the right side to the right side. Switch the
Printhead used once in the left side to the left side.
Open the Top Cover. Replace the Printhead L with a new one if Printhead L is displayed and the Printhead R if
Printhead R is displayed. If neither left or right is indicated, replace both Printhead L and Printhead R with new ones.
(See "Replacing the Printhead.")
Follow these steps to replace the Printhead.
1.
Open the Top Cover.
2.
Replace the Printhead L with a new one if Printhead L is displayed and the Printhead R if Printhead R is displayed. If
neither left or right is indicated, replace both Printhead L and Printhead R with new ones.
(See "Replacing the Printhead.")
Follow these steps to replace the Printhead.
1.
Turn off the printer, wait a while, and then turn it on again.
2.
Open the Top Cover.
3.
Replace the left printhead with a new one if Printhead L is displayed and the right one if Printhead R is displayed. If
neither left or right is indicated, replace both printheads.
(See "Replacing the Printhead.")
Corrective Action
→P.927
→P.928
Corrective Action
Corrective Action
→P.929
Corrective Action
→P.929
→P.929
iPF6450
→P.796
→P.796
