Paper Detailed Settings Dialog Box

Each of the setting values for the paper type, print mode, and output profile as well as the adjustment values con-
figured in the Color Settings sheet (color or monochrome) are printed at the bottom of the paper. However, the
adjustment values for the Curves are not printed.
•
The job name when printing the adjustment pattern is "Original Image Name + Pattern-Print". For example, the print job
name for the image "ABC.jpg" is "ABC_Pattern-Print.jpg".
Note
• Maximize Dialog Box button
When this button is clicked, the Adjustment pattern setting dialog box is displayed enlarged to cover the entire
display screen.

Paper Detailed Settings Dialog Box

Paper Detailed Settings Dialog Box
This dialog box appears when you click the Advanced Settings button on the Main Sheet. You can set Drying Time
and Roll Paper Margin for Safety by media type.
• Roll Paper Margin for Safety
Near End Margin
This sets the length of the near end margin of the roll paper.
Printer Default
3mm
20mm
• Cut Speed
This selects the auto cut speed.
Printer Default
Fast
Standard
Slow
• Calibration Value
When calibration has been carried out on the printer, use this setting to choose whether or not to use the results.
484
Printer Default
Use Value
Setting
The settings of the printer operating panel are applied.
Print at a standard size.
*Select for Media Type that has no problem when printing with a standard size margin.
Select this when rubbing against the printhead occurs such as when using paper that tends to
curl.
Setting
The settings of the printer operating panel are applied.
Select this setting if cutting with the Standard setting is not clean.
Select this setting when you are not experiencing problems.
This helps prevent adhesive from sticking to the cutter and keeps the cutter sharp if you select it
when using adhesive paper.
Setting
The settings of the printer operating panel are applied.
The calibration results are used for printing.
Details
Details
Details
