Specifications

Spectrophotometer Unit Specifications

Spectrophotometer Unit Specifications
Specifications
Specifications
•
The following values may vary depending on the operating environment.
Important
Spectrophotometer Sensor
Model name
Measurement geometry conditions
Illumination
Measurement aperture
Spectral Output
Observer Angle
Illumination Type
Measurement Range
Repetition Accuracy
Instrument Error
Recommended calibration frequency
1038
X-Rite ILS25
0°/45° ANSI/ISO 5-4
Tungsten lamp with UV cut filter + UV-LED
Diameter 3.55 mm
31 points (400nm to 700nm 10nm gap)
2°/10°
A, C, D50, D55, D65, D75, F2, F7, F8, F10, F11, F12
0 to 150% reflection
Maximum dEcmc≦0.2 (White tile)
Maximum dEcmc≦0.6 (Black tile)
Average dEcmc≦0.5 (BCRA tile 12 color)
Max dEcmc ≤ 1.0 (12-color BCRA tiles)
Once per year
